What is Roof Sarking
Thermoseal™ roof sarking is A Protective 'Second Skin' installed under tiles to minimise weather-related water damage such as wind-driven rain entering the roof cavity. If rain enters the roof it can wet insulation, making it less effective, and cause ceiling staining in plasterboard. It also reflects up to 97% of radiant heat making your home more comfortable during summer and winter.
Benefits of Thermoseal™ Roof Sarking
For the Home Owner
Warmer In Winter, Cooler In Summer
Bradford Thermoseal™ trade; roof sarking reflects up to 97% of radiant heat keeping your home more comfortable during the blistering heat. During winter or cold nights, it also reflects heat back into the home keeping you warmer.
Protect Against Weather-Related Damage
Bradford Thermoseal™ trade; roof sarking provides A Protective Second Skin trade; underneath your roof tiles. It minimises wind driven rain entering the roof space that can potentially cause serious damage such as, mould growth in the timber frame or ceiling stains caused by water ingress. Bradford roof sarking is the ideal way to protect your home.
For the Builder
Tough Weather Barrier
Bradford Thermoseal™ trade; roof sarking acts as a secondary drainage path if wind driven rain enters into the roof space. It can help minimise rectification related work caused by heavy weather damage as water safely drains down into the gutter.
Thermoseal Roof Tile
Thermoseal Roof Tile is a heavy-duty weather barrier suitable for tiled roof applications. It provides a second skin to protect against rain or hail damage in the roof cavity.
- A Protective Second Skinntrade; that helps minimise wind driven rain and dust entering the roof space
- Improves thermal performance by reflecting up to 97% of radiant heat in the roof
- Suitable for BAL fire regions
Application
Bradford Thermoseal Roof Tile is suitable for use under tiled roofs. This product is not recommended under metal sheet roofs.
All tiled roofs with a pitch less than 18 degrees must be provided with sarking, regardless of rafter/truss chord length.
Product Specifications
| Product Name | Width (mm) | Length (m) | m2 Per Roll | Weight | Product Code |
|---|---|---|---|---|---|
| Roof Tile | 1350 | 60 | 81 | 22.82 | 15109 |
| Roof Tile | 1500 | 30 | 45 | 13.35 | 15110 |
Find out more:
Thermoseal Roof Tile Plus
Thermoseal Roof Tile Plus is an extra heavy duty weather barrier for use under tiled roofs in coastal and high wind regions. Its extra heavy duty design is recommended when building in regions with more extreme weather conditions.
- A Protective Second Skinntrade; that helps minimise wind driven rain and dust entering the roof space
- Improves thermal performance by reflecting up to 97% of radiant heat in the roof
- Suitable for BAL fire regions
Application
Bradford Thermoseal Roof Tile Plus is suitable for use under tiled roofs. This product is not recommended under metal sheet roofs.
All tiled roofs with a pitch less than 18 degrees must be provided with sarking, regardless of rafter/truss chord length.
Product Specifications
| Product Name | Width (mm) | Length (m) | m2 Per Roll | Weight | Product Code |
|---|---|---|---|---|---|
| Roof Tile Plus | 1500 | 30 | 45 | 17.56 | 27308 |
Find out more:
Roof Metal Wall
Thermoseal Roof Metal Wall is a light duty weather barrier for use under metal deck roofs. It is designed to withstand higher temperatures and provide additional R-Values improving thermal performance of the roof. Its combination of reflective and semi-reflective surfaces boosts the thermal performance of the roof keeping the home warmer in winter and cooler in summer.
- A Protective Second Skinntrade; that helps minimise wind driven rain and dust entering the roof space
- Improves thermal performance by reflecting up to 97% of radiant heat in the roof
- Suitable for BAL fire regions
Application
Bradford Thermoseal Roof Metal Wall is suitable for use under metal sheet roofs. This product is not recommended under roof tiles.
Product Specifications
| Product Name | Width (mm) | Length (m) | m2 Per Roll | Weight | Product Code |
|---|---|---|---|---|---|
| Roof Metal Wall | 1350 | 30 | 40.5 | 9.95 | 105871 |
| Roof Metal Wall | 1350 | 60 | 81 | 21.1 | 15056 |
For additional sizes or custom printed stock please contact your Account Manager for more information or call 1300 850 305. Minimum order quantities apply.
Find out more:
Thermoseal ResiWrap
Thermoseal ResiWrap is an extra heavy duty weather barrier for use under metal roofs. It can also be used in brick veneer walls. This product's strength makes it ideal for use where harsh weather conditions may be experienced during construction. It reflects up to 97% of radiant heat improving the thermal performance of the roof.
- An extra tough weather barrier
- Ideal for high wind and harsh weather climate zones
- Suitable for BAL fire regions
Application
Bradford Thermoseal ResiWrap is suitable for use in residential metal sheet roof construction. This product is not recommended for tile roofs.
Product Specifications
| Product Name | Width (mm) | Length (m) | m2 Per Roll | Weight | Product Code |
|---|---|---|---|---|---|
| ResiWrap | 1350 | 30 | 40.5 | 7.83 | 108879 |
| ResiWrap | 1350 | 60 | 81 | 15.66 | 108004 |
| ResiWrap | 1500 | 30 | 45 | 8.59 | 120121 |
For additional sizes or custom printed stock please contact your Account Manager for more information or call 1300 850 305. Minimum order quantities apply.
Find out more:
Datasheets
- Thermoseal Resiwrap Product Technical Statement (Datasheet)
- Thermoseal Roof Metal Product Technical Statement (Datasheet)
- Thermoseal Roof Tile Product Technical Statement (Datasheet)
- Thermoseal Roof Tile Plus Product Technical Statement (Datasheet)
- Thermoseal 733MD Sarking Product Technical Statement (Datasheet)
- Thermoseal 753HD Sarking Product Technical Statement (Datasheet)
