Bradford WindMaster™ & WindMaster BAL Roof Ventilator
WindMaster is a wind-driven roof ventilator that helps exhaust air from roof spaces without using electricity. Made from lightweight aluminium, it reduces heat load and moisture in the roof cavity, helping to create a healthier home with no running costs. WindMaster comes in a wide range of colours to suit metal and tiled roofs and includes a 15-year warranty for long-term peace of mind.
For homes in bushfire-prone areas, WindMaster BAL offers the same wind-driven ventilation with a full-metal, non-combustible build that's rated for use up to BAL 40 when installed to specification. It removes stale air from the roof space without electricity and is available in matching colours for a neat finish.
.png&w=1640&q=80)
Features and Benefits
WindMaster is a wind driven natural ventilator designed to exhaust heat and moisture from the roof space, without the use of electrical energy.
WindMaster BAL adds confidence for bushfire design requirements up to BAL 40 with durable, all-metal construction.
Key Features
Heat and moisture management
Helps reduce heat load and the risk of condensation in the roof space
Energy efficient
Ventilates without electricity for year-round efficiency
Easy to install
Fits most metal or tiled roofs
Range
WindMaster
Classic, aluminium, wind-driven ventilator for residential roofs.
WindMaster BAL
Wind-driven ventilator with full-metal, non-combustible construction, rated for use up to BAL 40 when installed to specification.
| Classic Cream™ | Paperbark® | Gully® | Surfmist® | Evening Haze® |
| Pale Eucalypt® | Cottage Green® | Jasper® | Headland® | Manor Red® |
| Dover White™ | Southerly® | Bluegum® | Shale Grey™ | Dune® |
| Windspray® | Basalt® | Wallaby® | Woodland Grey® | Deep Ocean® |
| Ironstone® | Monument® | Night Sky® | Mill (uncoated aluminium) | |
The COLORBOND® steel colour swatches and images shown have been reproduced to represent actual product colours as accurately as possible. However, we recommend checking your chosen colour against an actual sample of the product before purchasing as varying light conditions and limitations of the printing process may affect colour tones. COLORBOND®, BlueScope, ™ and ® Colour names are registered trademarks of BlueScope Steel Limited.
Technical Specifications
|
General |
|
|
Ventilator Type |
Natural Roof Ventilator |
|
Turbine Diameter |
420 mm |
|
Varipitch Diameter |
306 mm |
|
Throat Open Area |
62,500 mm² |
|
Product Weight |
1.9 kg |
|
Roof Pitch |
Tiled Roofs: 15° to 45° Metal Sheet Roofs: 3° to 45° Note: Complies with AS1562.1, NCC & Australian Standards |
|
Material |
|
|
Turbine |
Aluminium |
|
Varipitch |
Aluminium |
|
Flashing |
Aluminium |
|
Shaft |
Zinc passivate plated mild steel |
|
Bearing Holder, Support Ring, Brackets |
Glass-Filled Nylon |
|
Screws |
Stainless Steel and Galvanised |
| Colour | Windmaster Product Code | Windmaster BAL Product Code |
| Basalt® | 125752 | 485201 |
| Bluegum® | 481726 | 485202 |
| Classic Cream™ | 61151 | 485203 |
| Cottage Green® | 61148 | 485204 |
| Deep Ocean® | 61159 | 485205 |
| Dover White™ | 481724 | 485206 |
| Dune® | 61153 | 485207 |
| Evening Haze® | 90673 | 485208 |
| Gully® | 125751 | 485209 |
| Headland® | 61145 | 485211 |
| Ironstone® | 61166 | 485212 |
| Jasper® | 61161 | 485213 |
| Manor Red® | 61146 | 485214 |
| Mill | 61141 | 485200 |
| Monument® | 90675 | 485215 |
| Night Sky® | 61144 | 485216 |
| Pale Eucalypt® | 61147 | 485217 |
| Paperbark® | 61152 | 485218 |
| Shale Grey™ | 61155 | 485219 |
| Southerly® | 481725 | 485220 |
| Surfmist® | 61143 | 485221 |
| Wallaby® | 125756 | 485222 |
| Windspray® | 61154 | 485223 |
| Woodland Grey® | 61149 | 485224 |
- Reduction of heat and moisture in roof spaces
- Suitable for metal and tiled roofs and most roof colours
- Suitable for residential buildings.
