Roof Safety Mesh
Bradford Roof Safety Mesh is a compliant fall protection system for commercial and industrial metal roofing. It meets AS/NZS 4389:2015 requirements and provides safety both during roof installation and throughout the service life of the roof. Cut-to-length rolls are available, subject to minimum order quantities.
Features and Benefits
Bradford Roof Safety Mesh delivers fall protection during roof construction and ongoing safety once installed. Compliant with AS/NZS 4389:2015, it is manufactured from durable galvanised steel, with PVC-coated options available for corrosive or high-salinity environments. Cut-to-length rolls can be supplied to suit project needs (subject to minimum order quantities), and installation is supported with a full range of mesh fasteners and staple guns.
Key Features
Fall protection
Provides safety during roof installation and ongoing service life
Complies with standards
Designed and manufactured to AS/NZS 4389:2015 Safety Mesh
Durable options
Available in galvanised or PVC-coated finishes for corrosive environments
Project-ready
Cut-to-length rolls and installation accessories available (MOQs apply)
Roof Safety Mesh Range
Roof Safety Mesh 2.0 mm
Available in standard galvanised mesh in multiple lengths.
Roof Safety Mesh Accessories
Fasteners and staple gun available to support secure installation.
Technical Specifications
Roof Safety Mesh
| GAUGE (mm) | DIMENSIONS | PRODUCT CODE |
| 2.0 | 50m x 1800mm | 17387 |
| 2.0 | 50m x 2250mm | 80676 |
| 2.0 | 50m x 2400mm | 87262 |
Roof Safety Mesh Accessories
| PRODUCT | QTY PER CARTON | PRODUCT CODE |
| Safety Mesh Metal Fasteners/Staples | 1000 | 151954 |
| Staples Fastner Gun | 1 | 151955 |
Roof Safety Mesh with PVC Coating
PVC coated mesh provides an improved level of protection against salinity, acidity, or alkalinity.
Subject to minmum order quantities.
| PRODUCT | GAUGE (mm) | DIMENSIONS | PRODUCT CODE |
Roof Safety Mesh - PVC Coating | 2.0 | 50m x 1800mm | 17391 |
| 2.0 | 50m x 1800mm | 17390 |
Supporting Mesh - Insulmesh 1.25mm
Light grade welded wiremesh, suitable for supporting insulation foils when installed under metal deck roofs. Not suitable for use as a roof safety mesh as it does not comply with AS4389
| PRODUCT | GAUGE (mm) | DIMENSIONS | PRODUCT CODE |
| Supporting Mesh - Insulmesh 1.25mm | 1.25 | 50m x 1800mm | 17384 |
Items are Limited Stock or Made-to-order. Subject to minimum order quantity.
Cut to length rolls available for Roof Safety Mesh, subject to minimum order quantities.
- Fall protection during installation and ongoing safety in service
- Suitable for commercial and industrial metal roofs
- PVC-coated mesh recommended for corrosive or high-salinity environments
- Insulmesh 1.25 mm for supporting insulation foils (not compliant as roof safety mesh)
