Bradford Hurricane® Natural Roof Ventilator
Bradford Hurricane is a high-performance, wind-driven roof ventilator that helps clear hot, stale and humid air from commercial and industrial buildings without using mains power. The vertical-vane turbine design extracts heat and moisture to support cooler, drier, safer interiors while reducing the load on mechanical cooling.
Built for demanding sites, Hurricane pairs robust aluminium construction with a lightweight form that's easy to install on new builds or retrofits. Finish and variant options suit coastal and corrosive environments, bushfire-prone areas and high temperature applications, giving specifiers a reliable, low-energy way to improve air movement at scale.
Features and Benefits
Bradford Hurricane promotes continuous airflow through large volumes, helping to lower internal heat build-up, reduce condensation and improve air quality for occupants. The wind-powered design means no running costs, and the low mass and variable-pitch bases simplify installation across common roof slopes. With durable materials, tested performance and optional dampers and bases, Hurricane delivers dependable, low-maintenance ventilation that can also reduce HVAC energy use and total cost of ownership over time.
Key Features
Natural, no-energy operation
Wind-driven extraction lowers heat load and humidity with zero power draw
High airflow, low maintenance
Vertical-vane turbine delivers strong throughput with minimal service needs
Engineered for harsh sites
Marine-grade equivalent aluminium as standard, with options for coastal, corrosive and bushfire-prone locations
Flexible integration
Lightweight body, variable-pitch bases and damper options for new build or retrofit projects
Range
Sizes (turbine diameter): 300, 400, 450, 500, 600, 700, 900 mm
Construction: Aluminium turbine, varipitch base and flashing; mill finish or powder-coat to common COLORBOND® colours
- Special variations: FR (Fire-Rated): high temperature exhuast release capability in the event of a fire
- BAL (Bushfire Rated): designed to comply with AS 3959 requirements for bushfire-prone areas
- S2 (Corrosion Resistant): polyolefin-coated turbine for moisture-rich or oxidative environments (e.g., reservoirs)
- HI (Heavy Industrial): enhanced resistance for highly corrosive industrial sites.
| Classic Cream™ | Paperbark® | Gully™ | Surfmist® | Evening Haze® |
| Pale Eucalypt® | Cottage Green® | Jasper® | Headland® | Manor Red® |
| Dover White® | Southerly® | Bluegum® | Shale Grey® | Dune® |
| Windspray® | Basalt® | Wallaby® | Woodland Grey® | Deep Ocean® |
| Ironstone® | Monument® | Night Sky® | Mill (uncoated aluminium) | |
The COLORBOND® steel colour swatches and images shown have been reproduced to represent actual product colours as accurately as possible. However, we recommend checking your chosen colour against an actual sample of the product before purchasing as varying light conditions and limitations of the printing process may affect colour tones. COLORBOND®, BlueScope, ® Colour names are registered trademarks of BlueScope Steel Limited.
Technical Specifications
Hurricane Standard (H) Turbine Ventilator
| Variant | Product Code |
| Hurricane 300mm Mill Finished | 61504 |
| Hurricane 300mm Custom | 600670 |
| Hurricane 400mm Mill Finished | 61530 |
| Hurricane 400mm Custom | 600671 |
| Hurricane 450mm Mill Finished | 61556 |
| Hurricane 450mm Custom | 600672 |
| Hurricane 500mm Mill Finished | 61582 |
| Hurricane 500mm Custom | 600673 |
| Hurricane 600mm Mill Finished | 61608 |
| Hurricane 600mm Custom | 600674 |
| Hurricane 700mm Mill Finished | 61634 |
| Hurricane 700mm Custom | 600675 |
| Hurricane 900mm Mill Finished | 61686 |
| Hurricane 900mm Custom | 600677 |
Accessories: Manual and electric dampers, special bases (ridge, spigot, square-to-round), grilles and damper grilles.
Product Information Summary H100 / H150 / H300 / H40
| Ventilator Range | Hurricane® | |||
| Ventilator Model | H300 | H400 | ||
| Ventilator Type (AS/NZS 4740:2000 cl 1.5) | Type 4 – Rotating Wind-Driven Roof Ventilator | |||
| Ventilator Performance Class (AS/NZS 4740:2000 Table 1.2) | ||||
| Rain Resistance | 50 m/s No Water - Class A | 50 m/s No Water - Class A | ||
| Effective Aerodynamic Area, EAA | 0.044 m² | 0.082 m² | ||
| Discharge Coefficient, Cd | 0.712 - Class 1 | 0.731 - Class 1 | ||
| Flow Coefficient, Cf | 0.27 - Class 3 | 0.24 - Class 4 | ||
| Nominal Performance* (m³/h) | ||||
| 0 m/s | 375 m³/h | 699 m³/h | ||
| 3 m/s | 397 m³/h | 742 m³/h | ||
| 6 m/s | 457 m³/h | 857 m³/h | ||
| *In accordance to AS/NZS 4740:2000 nominal performance parameters where h = 6m, ΔT = 14°C, T = 20°C | ||||
Product Information Summary H450 / H500 / H600
| Ventilator Range | Hurricane® | ||
| Ventilator Model | H450 | H500 | H600 |
| Ventilator Type (AS/NZS 4740:2000 cl 1.5) | Type 4 – Rotating Wind-Driven Roof Ventilator | ||
| Ventilator Performance Class (AS/NZS 4740:2000 Table 1.2) | |||
| Rain Resistance | 50 m/s No Water - Class A | 50 m/s No Water - Class A | 50 m/s No Water - Class A |
| Effective Aerodynamic Area, EAA | 0.108 m² | 0.137 m² | 0.165 m² |
| Discharge Coefficient, Cd | 0.764 - Class 1 | 0.780 - Class 1 | 0.639 - Class 2 |
| Flow Coefficient, Cf | 0.30 - Class 3 | 0.31 - Class 3 | 0.24 - Class 4 |
| Nominal Performance* (m³/h) | |||
| 0 m/s | 921 m³/h | 1169 m³/h | 1408 m³/h |
| 3 m/s | 988 m³/h | 1259 m³/h | 1475 m³/h |
| 6 m/s | 1165 m³/h | 1497 m³/h | 1660 m³/h |
| *In accordance to AS/NZS 4740:2000 nominal performance parameters where h = 6m, ΔT = 14°C, T = 20°C | |||
Product Information Summary H700 / H900
| Ventilator Range | Hurricane® | |
| Ventilator Model | H700 | H900 |
| Ventilator Type (AS/NZS 4740:2000 cl 1.5) | Type 4 – Rotating Wind-Driven Roof Ventilator | |
| Ventilator Performance Class (AS/NZS 4740:2000 Table 1.2) | ||
| Rain Resistance | 50 m/s No Water - Class A | 50 m/s No Water - Class A |
| Effective Aerodynamic Area, EAA | 0.226 m² | 0.372 m² |
| Discharge Coefficient, Cd | 0.631 - Class 2 | 0.63 - Class 2 |
| Flow Coefficient, Cf | 0.18 - Class 4 | 0.22 - Class 4 |
| Nominal Performance* (m³/h) | ||
| 0 m/s | 1929 m³/h | 3175 m³/h |
| 3 m/s | 1978 m³/h | 3297 m³/h |
| 6 m/s | 2119 m³/h | 3638 m³/h |
| *In accordance to AS/NZS 4740:2000 nominal performance parameters where h = 6m, ΔT = 14°C, T = 20°C | ||
- Warehousing, logistics and manufacturing
- Retail sheds, showrooms and distribution centres
- Schools, gyms, auditoriums and community buildings
- Agricultural and livestock facilities
- Cold storage and food processing (with suitable variant)
- Water treatment plants and reservoirs (corrosion-resistant variant)
- Bushfire-prone projects requiring BAL-rated ventilation (BAL variant)
- Facilities requiring high temperature release (FR variant)
